4-Port HDMI Splitter | 4K 60Hz | Built-In Scaler | 3.5mm, Optical, and HDMI Audio
This 4-port HDMI splitter with built-in scaler connects an HDMI video source to four HDMI displays, with support for UHD 4K resolutions, HDR (High Dynamic Range), and 7.1 channel audio.
4K 60Hz Resolution
This 4-way HDMI splitter supports up to 4K 60Hz resolution, at 4:4:4 chroma subsampling. The built-in scaler enables enables the concurrent output of 2 resolutions, ideal for environments where there is a variety of displays, monitors, and projectors.
Flexible Audio
This 4K HDMI Splitter features HDMI, 3.5mm, and Optical audio outputs, enabling connections to a variety of speakers and/or amplifiers. Simultaneous audio output is supported across all the audio ports.
Robust Installation Options
This HDMI splitter supports active HDMI cables and HDMI extenders (sold separately), facilitating installations at a distance from the displays (e.g., within a remote AV component cabinet). The metal enclosure and 8kV air and 4kV contact Electro-static Discharge (ESD) protection is suitable for installation in a variety of environments.
This product is backed for 2-years, including free lifetime 24/5 multi-lingual technical assistance.
The StarTech.com Advantage
| Ports & interfaces |
|---|
| Audio ports quantity |
2 |
| HDMI version |
2.0b |
| Video out |
4x HDMI |
| Video port type |
HDMI |
| Video ports quantity |
4 |
| Features |
|---|
| LED indicators |
Yes |
| Supported graphics resolutions |
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160 |
| Plug and Play |
Yes |
| Maximum refresh rate |
60 Hz |
| Maximum operating distance |
5 m |
| HD type |
4K Ultra HD |
| Maximum resolution |
3840 x 2160 pixels |
| Housing material |
Metal |
| Product colour |
Black |
| Power |
|---|
| Power consumption (typical) |
0.1 W |
| Output current |
1 A |
| Output voltage |
5 V |
| Input current |
0.35 A |
| AC input voltage |
100 - 240 V |
| Weight & dimensions |
|---|
| Weight |
248 g |
| Height |
14 mm |
| Depth |
180 mm |
| Width |
62 mm |
| Packaging data |
|---|
| Package weight |
500 g |
| Package height |
55 mm |
| Package depth |
150 mm |
| Package width |
213 mm |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Manual |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
20 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Technical details |
|---|
| Audio support |
Yes |
| Compliance certificates |
CE, RoHS |
| Supported audio channels |
7.1 |
| Logistics data |
|---|
| Products per master (outer) case |
20 pc(s) |
| Master (outer) case height |
318 mm |
| Master (outer) case length |
300 mm |
| Master (outer) case width |
443 mm |
