Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs
| Ports & interfaces |
|---|
| Port multiplier |
Yes |
| SATA revision |
3.0 |
| Output interface |
mSATA |
| Host interface |
SATA |
| Design |
|---|
| Certification |
CE, FCC |
| Hot-swap |
No |
| Mean time between failures (MTBF) |
5101299 h |
| Product colour |
Black, Green |
| Internal |
Yes |
| Features |
|---|
| Plug and Play |
Yes |
| RAID levels |
0, 1, BIG, JBOD |
| Data transfer rate (max) |
6 Gbit/s |
| Chipset |
JMicron JMS562 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 85 °C |
| System requirements |
|---|
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Windows operating systems supported |
Yes |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Weight |
39 g |
| Height |
7 mm |
| Depth |
97 mm |
| Width |
70 mm |
| Packaging data |
|---|
| Package weight |
107 g |
| Package height |
32 mm |
| Package depth |
145 mm |
| Package width |
174 mm |
| Quick installation guide |
Yes |
| Mounting brackets included |
Yes |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
