SKU: SFP-10GB-BX-U-STA-ST

StarTech.com MSA Compliant SFP+ Transceiver Module - 10GBase-BX (Upstream)~MSA Uncoded SFP+ Module - 10GBASE-BX - 10 Gigabit Ethernet Bi-Directional (BiDi) Fiber Single Strand SFP+ (Upstream) - LC 10km

StarTech.com
£112.06
iFrame
  • MSA UNCODED SFP+ TRANSCEIVER: 10 Gigabit Ethernet BiDi Fiber Single Strand SFP+ designed, programmed and tested to work with compatible MSA Compliant switches and routers to deliver reliable 10GbE connectivity
  • INCREASE BANDWIDTH ON EXISTING INFRASTRUCTURE: This 10 Gigabit Ethernet bi-directional WDM SFP+ transceiver module sends and receives over a single strand of fiber optic cable instead of two
  • TECHNICAL SPECS: 10GBASE-BX / 10Gbps / 10G Bi-Directional Upstream / Single Mode (SMF) / LC Connector / 1270nmTx/1330nmRx / Digital Diagnostic Monitoring (DDM) / Distances up to 10km (6.2mi)
  • THE IT PRO’S CHOICE: Designed and built for IT Professionals, this SFP module is backed for life (lifetime of module, not network switch), including free lifetime 24/5 multi-lingual technical assistance
  • WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules

10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime Warranty

The SFP-10GB-BX-U-STA-ST is a MSA compliant upstream fiber SFP+ transceiver which pairs with StarTech.com's SFP-10GB-BX-D-STA-ST. They are designed, programmed and tested to work with 10GBASE-BX compatible MSA switches and routers. The SFP+ transceiver module supports a maximum distance of up to 10 km (6.2 mi) and delivers dependable 10 GbE connectivity over fiber cabling.

Technical Specifications:

• Wavelength: 1270nmTx/1330nmRx
• Maximum Data Transfer Rate: 10Gbps
• Type: Single Mode Fiber
• Connection Type: LC Connector
• Maximum Transfer Distance: 10 km (6.2 mi)
• Power Consumption:
• DDM: Yes

This SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.

StarTech.com SFPs

All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.

The StarTech.com Advantage

Performance
Digital Diagnostics Monitoring (DDM) Yes
Rx wavelength (min) 1330 nm
Tx wavelength (min) 1270 nm
Maximum transfer distance 10000 m
SFP transceiver standard BX-U
Fiber optic connector LC
Multi-mode fiber (MMF) supported No
Single-mode fiber (SMF) supported Yes
Interface type SFP+
Maximum data transfer rate 10000 Mbit/s
SFP transceiver type Fiber optic
Features
Brand compatibility MSA Compliant
Hot-swap Yes
Product colour Silver
Power
Power consumption (typical) 1.3 W
Certificates
Certification CE, FCC, UL
Weight & dimensions
Weight 24 g
Packaging content
Quantity per pack 1 pc(s)
Packaging data
Package height 31 mm
Package depth 115 mm
Package width 90 mm
Logistics data
Products per master (outer) case 1 pc(s)
Master (outer) case height 31 mm
Master (outer) case length 115 mm
Harmonized System (HS) code 85369010
Master (outer) case width 90 mm
