One Shot, Huge Vision
8MP IR Panoramic Turret Network Camera
Cut Project Costs with 180° View and 4K (8MP) Clarity
General cameras require multiple units to cover blind spots in large spaces like hotel lobbies, playgrounds, intersections, and warehouses, raising costs. A single panoramic camera with 180° view and 4K resolution reduces installation, deployment, and maintenance costs while covering more area.
Powerful, Efficient Monitoring with Active Defense
Active Defense is a monitoring feature that uses deep learning algorithms or external alarm devices to trigger flashing lights and loud sounds in real time, deterring intruders. It also supports user-created custom voice audio.
Red-Blue Warning Lights with
Stronger Deterrence
Red-blue flashing lights are more effective than white lights and create a strong deterrent effect when paired with audio alarms.
Flexible Audio & Alarm Integration
The Audio In/Out and Alarm In/Out ports enable easy integration with external alarm or access control devices.
Instant Event Notifications
When the AI function detects an event or an external alarm device senses an event and sends a signal to the IPC, the alarm will trigger with alerts instantly sent to your phone.
VIGI AI Detection Technology
People & Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, upper body color, vehicle type, making post-event search faster and easier.*2
Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
| Performance |
|---|
| Dynamic range |
120 dB |
| Remote viewing |
Yes |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Wide Dynamic Range (WDR) |
Yes |
| Maximum operating distance |
44 m |
| Connectivity technology |
Wired |
| Placement supported |
Outdoor |
| Type |
IP security camera |
| Design |
|---|
| Weatherproof |
Yes |
| International Protection (IP) code |
IP67 |
| Protection features |
Waterproof |
| Housing material |
Metal |
| Product colour |
White |
| Mounting type |
Wall |
| Form factor |
Turret |
| Camera |
|---|
| Camera shutter speed |
1/3 to 1/10000 |
| Tilt angle range |
0 - 90° |
| Lens viewing angle, diagonal |
180° |
| Lens viewing angle, vertical |
86° |
| Lens viewing angle, horizontal |
180° |
| Minimum illumination |
0 lx |
| Image sensor |
|---|
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") |
| Sensor type |
CMOS |
| Panoramic camera |
|---|
| Sensor type (panoramic camera) |
CMOS |
| Lens system |
|---|
| Fixed focal length |
1.65 mm |
| Maximum aperture number |
2 |
| Identify distance |
4.4 m |
| Fixed focus |
Yes |
| Recognize distance |
8.8 m |
| Observe distance |
18.33 m |
| Detect distance |
44 m |
| Night vision |
|---|
| LED type |
IR/White |
| Night vision |
Yes |
| Video |
|---|
| Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) |
Yes |
| Image quality adjustment |
Brightness, Contrast, Mirror, Saturation, Sharpness |
| Bit rate |
Main Stream: 256 Kbps to 8 Mbps, Sub-Stream: 64 Kbps to 1024 Kbps |
| Back Light Compensation (BLC) |
Yes |
| Digital Wide Dynamic Range (DWDR) |
Yes |
| Video recording |
Yes |
| Supported graphics resolutions |
1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520, 2880 x 1620, 3840 x 2160 |
| Video compression formats |
H.264, H.264+, H.265, H.265+ |
| Total megapixels |
8 MP |
| Maximum resolution |
3840 x 2160 pixels |
| Network |
|---|
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| DC-in jack |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Detection distance |
120 m |
| Video motion detection |
Yes |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Motion sensor |
Yes |
| Alert notification type |
Push notification |
| Human and vehicle targets classification |
Yes |
| Password protection |
Yes |
| Built-in siren |
Yes |
| Power |
|---|
| DC output voltage |
12 |
| Power consumption (max) |
18 W |
| Power source type |
DC, PoE |
| Weight & dimensions |
|---|
| Height |
110.2 mm |
| Packaging content |
|---|
| Screws included |
Yes |
| Number of cameras |
1 |
