360° Coverage with 4-in-1 Cameras
A single fisheye camera can play the role of many, providing a simpler and more competitive security solution. For example, in 4PTZ display mode, it functions as four cameras at once, delivering complete coverage and flexible perspectives.
Multiple Display Modes
Along with the fisheye view, VIGI provides multiple display modes, enabling you to focus on every detail exactly as you prefer.
Smart Video Enhancement Technology
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
Performance |
Certification |
CE; NTRA; KC; FCC; VCCI; BSMI; ONVIF |
Dynamic range |
120 dB |
Day/night mode |
Yes |
Infrared (IR) cut-off filter |
Yes |
Wide Dynamic Range (WDR) |
Yes |
Connectivity technology |
Wired |
Placement supported |
Indoor |
Type |
IP security camera |
Design |
Weatherproof |
Yes |
IK code |
IK10 |
International Protection (IP) code |
IP67 |
Protection features |
Weatherproof |
Housing material |
Metal |
Product colour |
White |
Mounting type |
Ceiling/wall |
Camera |
Number of Privacy masking areas |
4 |
Camera shutter speed |
1/3 - 1/10000 s |
Lens viewing angle, diagonal |
180° |
Lens viewing angle, vertical |
180° |
Lens viewing angle, horizontal |
180° |
Minimum illumination |
0 lx |
Image sensor |
Progressive scan |
Yes |
Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") |
Sensor type |
CMOS |
Panoramic camera |
Digital Wide Dynamic Range (DWDR) (panoramic camera) |
Yes |
Signal-to-Noise Ratio (SNR) (panoramic camera) |
52 dB |
Sensor type (panoramic camera) |
CMOS |
Lens system |
Fixed focal length |
1.44 mm |
Maximum aperture number |
2 |
Identify distance |
2.8 m |
Recognize distance |
5.7 m |
Observe distance |
12 m |
Detect distance |
28.8 m |
Night vision |
Infra-red wavelength |
850 nm |
Number of illumination LEDs |
4 |
LED type |
IR |
Night vision distance |
10 m |
Night vision |
Yes |
Video |
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Highlight Compensation (HLC) |
Yes |
Region of Interest (ROI) encoding |
Yes |
Smart IR |
Yes |
Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
Bit rate |
64 Kbps to 6 Mbps |
Back Light Compensation (BLC) |
Yes |
Digital Wide Dynamic Range (DWDR) |
Yes |
Noise reduction technology |
3D noise reduction |
Video streaming |
Yes |
Frame rate |
30 fps |
Supported graphics resolutions |
320 x 240, 640 x 480 (VGA), 1280 x 960, 2048 x 1536 (QXGA), 2560 x 1920 |
Video compression formats |
H.264, H.264+, H.265, H.265+ |
Total megapixels |
5 MP |
Maximum resolution |
2560 x 1920 pixels |
Network |
Wi-Fi |
No |
Ethernet LAN |
Yes |
Storage |
Card reader integrated |
Yes |
Built-in HDD |
No |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
1 |
Security |
Video motion detection |
Yes |
IP address filtering |
Yes |
HTTPS encryption |
Yes |
Motion sensor |
Yes |
Alert notification type |
E-mail, Push notification |
Privacy protection |
Yes |
Password protection |
Yes |
Power |
DC output voltage |
12 |
Power consumption (max) |
11.76 W |
Power source type |
DC, PoE |
Weight & dimensions |
Diameter |
13.2 cm |
Height |
56 mm |
Packaging content |
Number of cameras |
1 |
Technical details |
Lens mount interface |
M12 |
