SKU: SG2428LP

TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+

TP-LINK
£247.58
  • 16× Gigabit 802.3af/at PoE+ ports
  • 8× Gigabit non-PoE RJ45 ports and 4× Gigabit SFP slots
  • 150 W total PoE budget with up to 30 W PoE output per port*
  • Centralized cloud management via the web or the Omada app†
  • Standalone management via web, CLI, SNMP, and RMON
  • Static Routing helps route internal traffic for higher efficiency
  • VLAN, ACL, QoS, and IGMP Snooping
  • Fanless design for quiet operation
  • Durable metal casing and rackmountable design

- 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
- 150 W Total PoE Budget
- Fanless Design for Silent Operation
- Zero-Touch Provisioning
- Centralized Management
- Omada App
- Static Routing
- Traffic Separation

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

Multiple Application Scenarios

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wi-Fi Coverage
Works with Access Points

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

Management features
ARP inspection Yes
Web-based management Yes
Cloud-managed Yes
Quality of Service (QoS) support Yes
Switch layer L2/L2+
Switch type Managed
Ports & interfaces
SFP module slots quantity 4
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Network
Number of VLANs 4000
Virtual LAN features MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
VLAN support Yes
Flow control support Yes
Link aggregation Yes
Spanning tree protocol Yes
Auto-negotiation Yes
10G support No
Networking standards IEEE 802.3af, IEEE 802.3at
Data transmission
Packet buffer memory 4.1 MB
Jumbo frames 9000
Jumbo frames support Yes
Forwarding rate 41.66 Mpps
Switching capacity 56 Gbit/s
MAC address table 8000 entries
Security
Password protection Yes
MAC address filtering Yes
IGMP snooping Yes
Access Control List (ACL) Yes
DHCP features DHCP relay, DHCP server
Multicast features
Multicast support Yes
Design
LED indicators Yes
Product colour Grey
Rack mounting Yes
Performance
Fanless Yes
Power
Power consumption (max) 184.7 W
AC input frequency 50/60 Hz
AC input voltage 100 - 240 V
Power source AC/PoE
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 150 W
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet plus (PoE+) ports quantity 16
Power over Ethernet (PoE) Yes
Operational conditions
Heat dissipation 628 BTU/h
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 10 - 90%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Height 44 mm
Depth 220 mm
Width 440 mm
General
Product family Omada
