TP-Link Omada PoE Splitter

SKU: POE10R

£25.02 inc. VAT

IEEE 802.3af compliant
Selectable power output
Gigabit speed support
Plug-and-Play, no configuration required

The PoE Splitter POE10R (TL-POE10R) fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK's TL-SF1008P or POE150S, or other equivalent product, to deliver 12V, 9V or 5V Direct Current to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.

Features
Plug and Play	Yes
LED indicators	Power
Product colour	Black
Power over Ethernet (PoE)	Yes
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u

Ports & interfaces
DC-out jack	Yes
RJ-45 output ports	1
RJ-45 input ports	1
Ethernet LAN (RJ-45) ports	2

Operational conditions
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%

Certificates
Certification	FCC, CE

Weight & dimensions
Height	24 mm
Depth	54 mm
Width	80.8 mm

Packaging content
Quantity per pack	1 pc(s)
Quick installation guide	Yes

Packaging data
Package type	Box

Power
Input voltage	5, 9, 12 V

General
Product family	Omada
