SKU: UX7

Ubiquiti UniFi Express 7 gateway/controller 10, 100, 1000, 2500, 10000 Mbit/s

Ubiquiti Networks
£189.26
  • 10,100,1000,2500,10000 Mbit/s Wi-Fi
  • Control display unit Built-in processor 1500 MHz 3000 MB
  • Antenna type: Internal 6 dBi
  • Quality of Service (QoS) support VLAN support
  • Enclosure material: Polycarbonate (PC)
  • White

Mesh-scalable, super-compact 10G Cloud Gateway with integrated WiFi 7.

Design
LED indicators Status
Enclosure material Polycarbonate (PC)
Product colour White
Features
Antennas quantity 4
Antenna gain level (max) 6 dBi
Antenna type Internal
Performance
Internal memory 3000 MB
Number of processors installed 1
Processor frequency 1500 MHz
Processor model Cortex-A53
Processor manufacturer ARM
Processor family ARM Cortex
Built-in processor Yes
Display type LCM
Control display unit Yes
Protocols
DHCP server Yes
Routing protocols OSPF
Network
Wireless connection Yes
Data transfer rate 5.7 Gbit/s
Load balancing Yes
Frequency band 2.4, 5, 6 GHz
Bluetooth Yes
WLAN data transfer rates supported 1,2,5.5,6,6.5,9,11,12,18,24,36,48,54,300 Mbit/s
Wi-Fi Yes
Networking standards IEEE 802.1Q
Ethernet LAN data rates 10,100,1000,2500,10000 Mbit/s
Security
Firewall security Yes
VLAN support Yes
Security algorithms 802.1x RADIUS, IPSec, PPSK, TLS, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3
Ports & interfaces
WAN connection Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports 2
Management features
Multicast support Yes
Reset button Yes
Quality of Service (QoS) support Yes
Power
Electromagnetic (EMP) protection (contact) 4 kV
Electromagnetic (EMP) protection (air) 8 kV
Electromagnetic (EMP) protection Yes
Input current 5 A
Input voltage 100 - 240 V
Power consumption (max) 22 W
Weight & dimensions
Weight 422 g
Width 117 mm
Depth 117 mm
Height 42.5 mm
Packaging content
Cables included LAN (RJ-45), Power
AC adapter included Yes
Operational conditions
Operating relative humidity (H-H) 5 - 95%
Operating temperature (T-T) -10 - 40 °C
Display
Display diagonal 2.44 cm (0.96")
Certificates
Compliance certificates CE, Federal Communications Commission (FCC), Industry Canada (IC)
