USB-C is the latest USB connector. It has a smaller reversible plug which supports USB 3.2 Gen 1 signal.
This cable is compatible with both 2-lane and 4-lane configurations. For a 4-lane connection, both connected devices must support 4 lanes.
Very Tough
This cable, reinforced with a Kevlar core, is designed to resist stretching forces. It can withstand a continuous force of up to 200 newtons or a momentary peak force of up to 400 newtons.
Tight Bends
Fiber cables boast a significantly tighter bend radius compared to copper cables. This particular cable features a dynamic bend radius of 20 mm and a static bend radius of 10 mm.
Directional
This cable contains a chip integrated into each connector, so the end marked 'display' must be connected to the display. The ends are not interchangeable.
| Features |
|---|
| Power consumption |
1.2 W |
| Reinforced charging cable |
Yes |
| Maximum resolution |
3840 x 2160 pixels |
| Maximum refresh rate |
60 Hz |
| DisplayPort version |
2.1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Fast charging |
Yes |
| Plug and Play |
Yes |
| Cable type |
Round cable |
| Product colour |
Black |
| Maximum data transfer rate |
10 Gbit/s |
| Cable jacket material |
Nylon/Polyvinyl Chloride (PVC) |
| Connector contacts plating |
Nickel |
| Connector 2 form factor |
Straight |
| Connector 1 form factor |
Straight |
| Connector 2 gender |
Male |
| Connector 1 gender |
Male |
| Connector 2 |
USB C |
| Connector 1 |
USB C |
| USB version |
USB 3.2 Gen 1 (3.1 Gen 1) |
| Power |
|---|
| Input voltage |
5 V |
| Input current (max) |
3 A |
| Weight & dimensions |
|---|
| Connector 1 dimensions (WxDxH) |
44 x 13 x 8 mm |
| Bend radius (min) |
1 cm |
| Cable diameter |
6.5 mm |
| Cable length |
10 m |
| Packaging data |
|---|
| Package weight |
850 g |
| Package height |
50 mm |
| Package depth |
150 mm |
| Package width |
175 mm |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Certificates |
|---|
| Compliance certificates |
CE, RoHS |
