The Yealink CM20 is a premium ceiling microphone, expertly crafted to enhance audio performance in professional conference settings. Boasting an advanced array of 16 omnidirectional microphones, the CM20 captures sound in 360°, ensuring clarity and inclusivity in every discussion. With an integrated DSP, CM20 offers plug-and-play functionality with Yealink MVC systems, removing the need for external audio processing.Designed for medium to large conference rooms, the CM20 combines advanced technology with a sleek, elegant design, making it a perfect blend of functionality and style.
| Features |
|---|
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate |
| Placement supported |
Ceiling |
| Product colour |
Grey |
| Product type |
Microphone |
| Microphone |
|---|
| Signal-to-Noise Ratio (SNR) |
86 dB |
| Number of microphone arrays |
16 |
| Microphone direction type |
Omnidirectional |
| Microphone frequency |
120 - 16000 Hz |
| Microphone sensitivity |
94 dB |
| Ports & interfaces |
|---|
| Device interface |
RJ-45 |
| Power |
|---|
| Power consumption (max) |
9 W |
| Power consumption (typical) |
5.7 W |
| Power source type |
PoE |
| Weight & dimensions |
|---|
| Weight |
615 g |
| Height |
83 mm |
| Depth |
223 mm |
| Width |
223 mm |
| Operational conditions |
|---|
| Storage temperature (T-T) |
0 - 70 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Operating temperature (T-T) |
0 - 50 °C |
| Packaging data |
|---|
| Package type |
Box |
| Package height |
135 mm |
| Package depth |
310 mm |
| Package width |
398 mm |
| Packaging content |
|---|
| Packaging content |
CM20 Microphone, White Mesh Cover (Black Optional), Quick Start Guide, Assembly Fixing Bracket, Dust Cover, Length-Adjustable Pole (Optional), Bracing Bridge*1 pair, Suspend Pole Adapter (Optional), Expansion Bolt*6 (φ6 * 30 mm, white, Polyamide), Self-tapping Screw*6 (T4*30mm), Machine Screw*5 (3*6PMOZN3+), Bracing Bredge Screw*20 (M3*6PWMHOZN3) |
| User guide |
Yes |
| Screws included |
Yes |
| Mounting kit |
Yes |
| Quantity |
1 |
