High-performance DECT IP base station for small and medium-sized businesses
The Yealink W70B is the DECT IP base station for small and medium-sized businesses. Paring with up to a total of 10 Yealink W73H/W56H/W59R/CP930W/color screen DDPhone (T54W+DD10K) DECT handsets, W70B allows you to enjoy superb mobility and efficient flexibility immediately as well as significantly eliminates additional wiring troubles and charges. A powerful chip ensuring a better and higher performance, this DECT IP base station not only supports up to 10 VoIP accounts and 20 simultaneous calls, but also speeds up its startup and signal connection, provides no perception upgrade, slashes its upgrade downtime as well.
Designed in modern and elegant style, this compact DECT IP base station possesses a wire-hidden design, presenting a concise and tidy desk to you even being mounted to the wall. By supporting Opus codec, Yealink W70B consistently delivers excellent and professional audio quality in both high-bandwidth and poor network conditions, comparing with other wideband or narrowband audio
The Yealink W70B DECT IP base station supports efficient provisioning and effortless mass deployment with Yealink’s Redirection and Provisioning Service (RPS) and Boot mechanism to help you realize the Zero Touch Provisioning without any complex manual settings, which makes it simple to deploy, easy to maintain and upgrade, saving even more time and IT costs for businesses
| Performance |
|---|
| XML browser |
Yes |
| Auto-provision |
Yes |
| Music on hold function |
Yes |
| Hearing aid compatibility |
Yes |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af |
| Voice codecs |
AGC, AJB, AMR-WB, CNG, G.722, G.726, G.729, G.729A, PLC, VAD, iLBC |
| DECT standards |
CAT-iq2.0 |
| Security algorithms |
AES, HTTPS, SHA-256, SHA-384, SHA-512, TLS |
| Management protocols |
SNTP/NTP, UDP/TCP/TLS |
| Number of VoIP accounts |
10 |
| CAT-iq |
2.0 |
| Maximum range |
300 m |
| Number of handsets supported (max) |
10 |
| Call management |
|---|
| System log export |
Yes |
| Emergency call |
Yes |
| Shared Call Appearance (SCA) |
Yes |
| Call history |
Yes |
| Reset function |
Yes |
| Phonebook search/import/export function |
Yes |
| Message Waiting Indication (MWI) function |
Yes |
| Redialing |
Yes |
| Integrated voicemail |
Yes |
| Speed dialling |
Yes |
| Switching between calls |
Yes |
| Mute function |
Yes |
| Call hold |
Yes |
| Call transfer |
Yes |
| Remote phonebook |
Yes |
| Call forwarding |
Yes |
| Caller ID |
Yes |
| Call waiting |
Yes |
| Anonymous call rejection |
Yes |
| Anonymous call |
Yes |
| Number of simultaneous calls (max) |
20 |
| Phonebook capacity (per handset) |
1000 entries |
| Number of parallel conferences |
3 |
| Conference call |
Yes |
| Antenna |
|---|
| Frequency range (US) |
1920 - 1930 MHz |
| Frequency range (EU) |
1880 - 1900 MHz |
| Ports & interfaces |
|---|
| Ethernet LAN data rate supported (max) |
100 Mbit/s |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Design |
|---|
| Certification |
CE, FCC, REACH |
| LED indicators |
Yes |
| Wall mountable |
Yes |
| Full duplex |
Yes |
| Product colour |
Grey |
| Power |
|---|
| Input voltage |
100 - 240 V |
| Output voltage |
5 V |
| Output current |
0.6 A |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Weight & dimensions |
|---|
| Package weight |
4.15 kg |
| Package height |
63 mm |
| Package depth |
180 mm |
| Package width |
174 mm |
| Weight |
3.61 kg |
| Dimensions (WxDxH) |
130 x 100 x 25.1 mm |
| Packaging content |
|---|
| Power adapter included |
Yes |
| Quick start guide |
Yes |
