Plug and play connectivity
Simply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivity without any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1p prioritization and jumbo frame, the switch ensures smooth voice and video traffic for your office network.
Whisper quiet operation
The GS1100 Series has fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model is specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.
Energy saving
The GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects network traffic and adjusts power consumption dynamically. Zyxel’s green features also adjust power consumption by detecting the link status and cable length reducing business operating expenses.
Support PoE+
The GS1100-10HP supports PoE+ (IEEE 802.3at) which provides a maximum of 30W per port, delivering fully automated support for powering compatible IP phones, video surveillance cameras or wireless access points.
Flexible choices for your office
The GS1100 Series switch offers multiple options including 8-port, 16-port, and 24-port for diversified office applications.
Management features |
Switch type |
Unmanaged |
Ports & interfaces |
Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity |
24 |
Network |
Auto MDI/MDI-X |
Yes |
10G support |
No |
Networking standards |
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Data transmission |
Packet buffer memory |
0.525 MB |
Jumbo frames |
10000 |
Forwarding rate |
35.7 Mpps |
Switching capacity |
48 Gbit/s |
MAC address table |
8000 entries |
Design |
Wall mountable |
Yes |
LED indicators |
Yes |
Product colour |
Black |
Rack mounting |
Yes |
Performance |
Mean time between failures (MTBF) |
366919 h |
Fanless |
Yes |
Power |
Power consumption (max) |
13 W |
AC input frequency |
50 - 60 Hz |
AC input voltage |
100 - 240 V |
Power supply included |
Yes |
Power over Ethernet (PoE) |
Power over Ethernet (PoE) |
No |
Operational conditions |
Heat dissipation |
43.53 BTU/h |
Operating temperature (T-T) |
0 - 40 °C |
Weight & dimensions |
Weight |
1.5 kg |
Height |
42 mm |
Depth |
162 mm |
Width |
267 mm |
Packaging content |
Rack mount kit |
Yes |
Cables included |
AC |
Certificates |
Certification |
LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH |
Logistics data |
Harmonized System (HS) code |
85176990 |
