Support 2.5 Gigabit High Network Speed
PoE12-30W is a Multi-Gigabit PoE injector supporting network speeds of up to 2.5Gbps. It is allowed to connect powered devices through existing Cat 5e or above cable.
High PoE Power
PoE12-30W complies with PoE+ providing PoE power budget up to 30 watts. It also offers interoperability and compatibility with other standard-based PoE devices.
Plug and Play—Ease of Use
PoE12-30W is easy to connect network devices without any configuration. The wall-mount and desktop design accommodate most installations scenarios.
| Network |
|---|
| Networking standards |
IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u |
| Power over Ethernet (PoE) |
Yes |
| Ethernet LAN data rates |
100,1000,2500 Mbit/s |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Features |
|---|
| Mean time between failures (MTBF) |
1869569 h |
| Plug and Play |
Yes |
| Easy to install |
Yes |
| Wall mountable |
Yes |
| Product colour |
Black |
| Ports & interfaces |
|---|
| RJ-45 output ports |
1 |
| RJ-45 input ports |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| Power |
|---|
| Total Power over Ethernet (PoE) budget |
30 W |
| Input current |
1 A |
| Input frequency |
50/60 Hz |
| Input voltage |
100 - 240 V |
| Operational conditions |
|---|
| Storage relative humidity (H-H) |
5 - 90% |
| Storage temperature (T-T) |
-25 - 70 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Operating temperature (T-T) |
14 - 113 °F |
| Weight & dimensions |
|---|
| Weight |
144 g |
| Height |
30 mm |
| Depth |
45.5 mm |
| Width |
140 mm |
| Packaging content |
|---|
| Power cord included |
Yes |
| Number of products included |
1 pc(s) |
| Packaging data |
|---|
| Package weight |
918 g |
| Package height |
42 mm |
| Package depth |
121 mm |
| Package width |
171 mm |
